Fluke 190-202 Oscilloscope, Handheld, 2-Channel, 200 MHz, color

EW-20041-34
$3,799.95 USD/EACH

Call 1-888-358-4705 for availability.
Qty:

  • The first high-performance two and four-channel scopes built for harsh industrial environments

  • Rugged, IP 51 rating, dust- and drip-proof

  • Connect-and-View™ triggering for intelligent, automatic triggering on fast, slow, and even complex signals

  • Automatic capture and replay of 100 screens

  • 30,000 points or more per input channel using ScopeRecord™ roll mode

  • TrendPlot™ Paperless recorder with deep memory for long-term automatic measurements

  • Frequency Spectrum using FFT-analysis

  • 5,000 count DMM (2-channel models only)

These portable oscilloscopes combine rugged portability with the performance of a bench scope, taking you from troubleshooting microelectronics all the way into power electronic applications. Designed for plant maintenance engineers there is now a four-channel scope for the harsh world of industrial electronics that allow you to easily measure input, output, and feedback signals simultaneously to diagnose industrial electronics. Additionally, units allow you to safely troubleshoot three-phase systems like variable speed drives, as well as UPS or back-up generators. See more, fix more, and go where you’ve never gone before with a scope.
Four channel models additional features include four independent isolated inputs, up to 1000 V,
high-speed sampling - up to 2.5 GS/sec, deep memory: 10,000 points per trace waveform capture, up to 7 hours of battery operation, isolated USB host port for direct data storage to a USB memory device, USB device port for easy PC communication, and security lock down capabilities.

Available for sale in the US and Canada only

What's Included:
BC190 power adapter, BP291 double-capacity Li-ion battery pack (4-channel models), BP290 double capacity Li-ion battery pack (2-channel models), VPS410-R red probe set, VPS410-B blue probe set, VPS410-G gray probe set, VPS410-V green probe set, USB cable with mini B connector, hanging strap, side strap, CD user manual with FlukeView ScopeMeter software demo version, and calibration document supplied by the manufacturer.
Specifications
Product Type Handheld Oscilloscopes
Bandwidth (MHz) 200
Input channels 2
Record length 27,500 pts per input
Display Full-color high resolution backlit LCD (153 mm), 320 x 240 pixels
Power Li-ion battery; 4-channel models (5200 mAh), 2-channel models (3600 mAh)
Inputs 2
Sample rate (Gs/s) 2.5
Channels 2
CE Compliance Yes
Model 190-202
Make Fluke
